A204 steel -- Shanghai Royal Industry

ASME SA302 Grade A steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in SA302 Gr A, SA302 Gr B , SA 302 Gr C and SA 302 Gr D. Standard: ASME SA-302/SA-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm ASME SA302 Grade A steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact Test Degree Min Value SA302Gr.A mm Min Mpa Mpa Min % - J 5≤t≤50 345 550-690 18% - 50≤t≤200 345 550-690 15% Note: Impact energy for impact test is on longitudinal SA302 Grade A Boiler steel plate Chemical Composition : Chemical Composition Grade The Elemen

ASME SA353 is a kind of Ni-alloy steel plates material. In order to meet the property of standard ASME SA353 , SA353 steel must be done twice Normalizing + once Tempering. The Ni composition in SA353 is 9%. Just because of this 9% Ni composition, SA353 have the very good resistant property to the high temperature. Standard : ASME SA353/SA353M Dimension range : 1.5mm -260mm * 1000mm-4000mm * 1000mm-18000mm ASME SA353 steel plate/sheet Mechanical Property : Mechanical Property Grade Thickness (mm) Yield Min Mpa Elongation Min % SA353 5 < t≦30 585-820 18 30 < t 575-820 18 ASME SA353 Boiler steel plate Chemical composition (%) : Chemical composition Grade C ≤ Mn ≤ P ≤ S ≤ Si Ni SA353 0.13 0.90 0.035 0.035 0.15~0.40 8.50~9.50 Delivery Status :

ASME SA302 Grade D steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in SA302 Gr A, SA302 Gr B , SA 302 Gr C and SA 302 Gr D . Standard: ASME SA-302/SA-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm SA302 Grade D steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact Test Degree Min Value SA302Gr.D mm Min Mpa Mpa Min % - J 5≤t≤50 345 550-690 20% - 50≤t≤200 345 550-690 17% Note: Impact energy for impact test is on longitudinal ASME SA302 Grade D Boiler steel plate Chemical Composition : Chemical Composition Grade The Eleme

ASME SA302 Grade C steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in SA302 Gr A, SA302 Gr B , SA 302 Gr C and SA 302 Gr D. Standard: ASME SA-302/SA-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm ASME SA302 Grade C steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact Test Degree Min Value SA302Gr.C mm Min Mpa Mpa Min % - J 5≤t≤50 345 550-690 20% - 50≤t≤200 345 550-690 17% Note: Impact energy for impact test is on longitudinal SA302 Grade C Boiler steel plate Chemical Composition : Chemical Composition Grade The Elemen

ASME SA302 Grade B steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in SA302 Gr A, SA302 Gr B , SA 302 Gr C and SA 302 Gr D. Standard: ASME SA-302/SA-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm SA302 Grade B steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact Test Degree Min Value SA302Gr.B mm Min Mpa Mpa Min % - J 5≤t≤50 345 550-690 18% - 50≤t≤200 345 550-690 15% Note: Impact energy for impact test is on longitudinal ASME SA302 Grade B Boiler steel plate Chemical Composition : Chemical Composition Grade The Eleme

SA285 Grade C is a kind of common carbon steel, whose tensile is low or mid-low. There are three grades or levels material GR A/B/C in the standard ASME SA-285/SA-285M. Plates ordered to this specification SA285 Grade C are normally in the as-rolled condition. SA285 Grade C may be ordered from the supplier as normalized or stress relieved if so desired.The alloy SA285 Grade C is not heat treated for hardening. SA285 Grade C is a kind of common carbon steel used for pressure vessel steel.SA285 Grade C is supplied throughout the oil gas and petrochemical industry.The material SA285 Grade C has good forming and welding characteristics under conventional methods. Standard: ASME SA-285/SA-285M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm SA285 Grade C steel plate/sheet Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact Test

ASME SA302 Grade A steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in SA302 Gr A, SA302 Gr B , SA 302 Gr C and SA 302 Gr D. Standard: ASME SA-302/SA-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm ASME SA302 Grade A steel plate/sheet Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact Test Degree Min Value SA302Gr.A mm Min Mpa Mpa Min % - J 5≤t≤50 345 550-690 18% - 50≤t≤200 345 550-690 15% Note: Impact energy for impact test is on longitudinal SA302 Grade A Boiler steel plate Chemical Composition : Chemical Composition Grade The Eleme

ASME SA302 Grade B steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in SA302 Gr A, SA302 Gr B , SA 302 Gr C and SA 302 Gr D. Standard: ASME SA-302/SA-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm SA302 Grade B steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact Test Degree Min Value SA302Gr.B mm Min Mpa Mpa Min % - J 5≤t≤50 345 550-690 18% - 50≤t≤200 345 550-690 15% Note: Impact energy for impact test is on longitudinal ASME SA302 Grade B Boiler steel plate Chemical Composition : Chemical Composition Grade The Eleme

SA285 Grade A is a kind of common carbon steel, whose tensile is low or mid-low. There are three grades or levels material GR A/B/C in the standard ASME SA-285/SA-285M. Plates ordered to this specification SA285 Grade A are normally in the as-rolled condition. SA285 Grade A may be ordered from the supplier as normalized or stress relieved if so desired.The alloy SA285 Grade A is not heat treated for hardening. SA285 Grade A is a kind of common carbon steel used for pressure vessel steel.SA285 Grade A is supplied throughout the oil gas and petrochemical industry.The material SA285 Grade A has good forming and welding characteristics under conventional methods. Standard: ASME SA-285/SA-285M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm ASME SA285 Grade A steel plate/sheet Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact T

SA285 Grade B is a kind of common carbon steel, whose tensile is low or mid-low. There are three grades or levels material GR A/B/C in the standard ASME SA-285/SA-285M. Plates ordered to this specification SA285 Grade B are normally in the as-rolled condition. SA285 Grade B may be ordered from the supplier as normalized or stress relieved if so desired.The alloy SA285 Grade B is not heat treated for hardening. SA285 Grade B is a kind of common carbon steel used for pressure vessel steel.SA285 Grade B is supplied throughout the oil gas and petrochemical industry.The material SA285 Grade B has good forming and welding characteristics under conventional methods. Standard: ASME SA-285/SA-285M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm ASME SA285 Grade B steel plate/sheet Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Notch Impact

A302 Grade D steel plate ASTM A302 Grade D steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in A302 Gr A, A302 Gr B , A 302 Gr C and A 302 Gr D. Standard: ASTM A-302/A-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm ASTM A302 Grade D Boiler steel plate Chemical Composition : Chemical Composition Grade The Element Max (%) C Si Mn P S Al N A302Gr.D 0.20-0.25 0.13–0.45 1.07-1.62 0,035 0,035 Nb V Ti Cu Cr Ni Mo 0.67-1.03 0.41–0.64 A302 Grade D steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Ch

A302 Grade C steel plate ASTM A302 Grade C steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in A302 Gr A, A302 Gr B , A 302 Gr C and A 302 Gr D. Standard: ASTM A-302/A-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm A302 Grade C Boiler steel plate Chemical Composition : Chemical Composition Grade The Element Max (%) C Si Mn P S Al N A302Gr.C 0.20-0.25 0.13–0.45 1.07-1.62 0,035 0,035 Nb V Ti Cu Cr Ni Mo 0.37-0.73 0.41–0.64 ASTM A302 Grade C steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Ch

A302 Grade B steel plate ASTM A302 Grade B steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in A302 Gr A, A302 Gr B , A 302 Gr C and A 302 Gr D. Standard: ASTM A-302/A-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm ASTM A302 Grade B Boiler steel plate Chemical Composition : Chemical Composition Grade The Element Max (%) C Si Mn P S Al N A302Gr.B 0.20-0.25 0.13–0.45 1.07-1.62 0,035 0,035 Nb V Ti Cu Cr Ni Mo 0.41–0.64 A302 Grade B steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V Not

A302 Grade A steel plate ASTM A302 Grade A steel plate grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in A302 Gr A, A302 Gr B , A 302 Gr C and A 302 Gr D. Standard: ASTM A-302/A-302M Dimension range :1.5mm -260mm x 1000mm-4000mm x 1000mm-18000mm A302 Grade A Boiler steel plate Chemical Composition : Chemical Composition Grade The Element Max (%) C Si Mn P S Al N A302Gr.A 0.20-0.25 0.13–0.45 1.07-1.62 0,035 0,035 Nb V Ti Cu Cr Ni Mo 0.41–0.64 ASTM A302 Grade A steel plate/shee Mechanical Properties : Mechanical Properties Grade Thickness Yield Strength Tensile Strength Elongation Charpy V No

A353 steel plate ASTM A353 is a kind of Ni-alloy steel plates material. In order to meet the property of standard ASTM A353, A353 steel must be done twice Normalizing + once Tempering. The Ni composition in A353 is 9%. Just because of this 9% Ni composition, A353 have the very good resistant property to the high temperature. Standard : ASTM A353/A353M Dimension range : 1.5mm -260mm * 1000mm-4000mm * 1000mm-18000mm ASTM A353 Boiler steel plate Chemical composition (%) : Chemical composition Grade C ≤ Mn ≤ P ≤ S ≤ Si Ni A353 0.13 0.90 0.035 0.035 0.15~0.40 8.50~9.50 ASTM A353 steel plate/sheet Mechanical Property : Mechanical Property Grade Thickness (mm) Yield Min Mpa Elongation Min % A353 5<t≦30 585-820 18 30<t 575-820 18 Delivery Stat
